KCl Crystals
High purity: Through a strict purification process, the impurity content in the KCl crystal is very low, which improves the stability and reliability of the product.
Excellent optical transparency: High-purity KCl crystals exhibit good optical clarity in the visible and near-infrared bands, making them suitable for applications such as optical windows and lenses.
Good thermal stability: KCl crystals have high melting point and thermal conductivity, and can maintain stable performance in high-temperature environments.
Chemical stability: It does not react easily with most acids, alkalis and organic solvents, and is suitable for use in a variety of chemical environments.
Wide range of applications: Due to their unique properties, KCl crystals have important applications in many fields such as optics, electronics, and chemical analysis.
Applications: Optics, Electronics, Chemical Analysis Field, etc.
Kingwin Optics’ high-purity KCl crystal is a crystal of inorganic compounds that has undergone precision purification. With its unique physical and chemical properties, KCl has shown a wide range of application potential in several fields. Our KCl crystals are prepared using advanced processes to ensure high purity, uniform crystal structure and excellent optical clarity to meet the demanding needs of scientific and industrial fields.
Specifications:
| Main performance parameters | |
| Crystal name | KCl |
| Crystal structure | a=6.291Å |
| Growth method | Crystallization |
| Through the band | 0.20~27.50um |
| density | 1.98（g/cm3） |
| melting point | 770℃ |
| Refractive index nd | 1.49025 |
| T (transmittance). | 0.91 |
| NF- (Impurity Absorption Front). | 0.01114 |
| Finish; Surface roughness | 60/40 ; <30nm |
| Crystal orientation | <111>.<110>.<100> |
| size | 10×10×2.0mm、20*20*2.0mm. It can be processed according to customer needs |
| polished | Single-sided or double-sided |
| wrap | Class 100 clean bag, Class 1000 clean room |
Features:
- High purity: Through a strict purification process, the impurity content in the KCl crystal is very low, which improves the stability and reliability of the product.
- Excellent optical transparency: High-purity KCl crystals exhibit good optical clarity in the visible and near-infrared bands, making them suitable for applications such as optical windows and lenses.
- Good thermal stability: KCl crystals have high melting point and thermal conductivity, and can maintain stable performance in high-temperature environments.
- Chemical stability: It does not react easily with most acids, alkalis and organic solvents, and is suitable for use in a variety of chemical environments.
- Wide range of applications: Due to their unique properties, KCl crystals have important applications in many fields such as optics, electronics, and chemical analysis.
Applications:
1.Optics:
- Optical window: The highly transparent KCl crystal can be used as an optical window material in the infrared and visible light bands.
- Lenses and prisms: With their optical properties, they can be processed into optical components such as lenses and prisms, which are used in spectrometers, lasers and other equipment.
2.Electronics:
- Piezoelectric components: KCl crystals have a certain piezoelectric effect, which can be used to make piezoelectric sensors, transducers and other electronic components.
- Electrolyte material: It is used as an electrolyte material in electronic devices such as solid-state batteries and supercapacitors.
3.Chemical Analysis Field:
- Ion exchangers: KCl crystals can be used to prepare ion exchange resins, which have important applications in chemical analysis and water treatment.
- Spectroscopic analysis: as a sample matrix or reference substance, it is used in analytical techniques such as atomic absorption spectroscopy and fluorescence spectroscopy.
